Product | Thickness | Dimensions | TCNA Robinson Wheel Test (ASTM C627) Typical Ratings |
R-value (US units; SI units) | Crack Isolation |
---|---|---|---|---|---|
4002 | 2mm | 2mm(⅛");48" x 75LF | Extra Heavy | 0.11; 0.02 | High Performance rating by TCNA per ANSI 118.12 5.4 (over 1/8" protection) |
4005 | 5mm | 5mm(¼");48" x 30LF | Light | 0.24; 0.04 | |
4010 | 10mm | 10mm(⅜");48" x 15LF | Residential | 0.44*; 0.08* | |
4012 | 12mm | 12mm(½");48" x 15LF | 0.52*; 0.09* | ||
5015 | 15mm | 15mm(⅝");48" x 15LF | 0.65*; 0.12* |
